Place of Origin:
Zhejiang, China
Brand Name:
CHIYANG
Model Number:
VH06
1.GENERAL
Frequency Ranges: TX: 156.025 MHz - 157.425 MHz
RX: 156.050 MHz - 163.275 MHz
Channel Spacing: 25 kHz
Frequency Stability: ±5 ppm
(–4 °F to +140 °F [–20 °C to +60 °C])
Emission Type: 16K0G3E
Antenna Impedance: 50 Ω
Supply Voltage: 7.4V DC
Current Consumption: 320 mA (Receive, Typical at AF MAX.)
50 mA (Standby), 1.6 A / 0.7 A (TX: 3.2 W / 1W)
Operating Temperature: –4 °F to +140 °F (–20 °C to +60 °C)
Case Size (W x H x D): 2.20” x 5.24” x 1.08” (56 x 133 x 27.5 mm)
(w/o knob & antenn
2.TRANSMITTER
RF Power Output: 3.2 W / 1 W (@7.4 V )
Modulation Type: Variable Reactance
Maximum Deviation: ±5 kHz
Spurious Emission: –75 dBc typical
Microphone Impedance: 2 kΩ
